GME RC900BT - Manual (Page 14)

PA G E 1 4 I N S T R U C T I O N M A N UA L R C 9 0 0 B T
*All specifications are typical and subject to change without notice or obligation.
SPECIFICATIONS*
FM RADIO
Frequency Range: 87.5 - 108 MHz (Eu./Aust./N.Z.)
87.5 - 107.9 MHz (U.S.A.)
Frequency Step: 50 kHz (Eu./Aust./NZ) 200 kHz /USA
Intermediate Frequency: 10.7 MHz
Sensitivity (30 dB S/N): 13 dBuV (typical)
Channel Separation: 32 dB
Station Memories: 18
AM RADIO
Frequency Range: 522 - 1620 kHz (Eu./Aust./N.Z.)
530 - 1710 kHz (U.S.A.)
Frequency Step: 9 kHz (Eu./Aust./N.Z.)
10 kHz (U.S.A.)
Intermediate Frequency: 450 kHz
Sensitivity (20 dB S/N): 17 dBuV
Station Memories: 12
COMPACT DISC MECHANISM
Mechanism: Auto Loading
Signal to Noise Ratio: 58 dB
Format: 8 Times Oversampling
Environmental: Anti-vibration/Anti-shock
AUDIO AMPLIFIER
Audio Output: (4 channels x 45 W Peak = 180 W Peak) @ 10% THD.
Speaker Impedance: 4 Ohm
Bass Adjustment Range: +/-10 dB
Treble Adjustment Range: +/-12 dB
GENERAL
DC Supply Input: 10 – 16 volts Negative Ground
Memory Back-up: External Back-up Memory Wire
Back-up Current: Approximately 16 mA
Overall Size: 232 mm (W) x 97 mm (H) x
200 mm (D) Excluding Heat Dissipater
Weight: 1.55 kg
Supply Current: 7 amps (max.)
