PA G E 6 I N S T R U C T I O N M A N UA L R C 9 0 0 B T
A range of GME speakers are available from your
local GME retailer.
Connect all four speakers as shown in the diagram
above. Adjust the Fader control for the required
front/rear balance.
If you wish to connect only two speakers, connect
these to the rear speaker wires. The remaining
speaker wires should be insulated to ensure they
cannot short circuit together or to the vehicle’s
12 volt or negative electrical Bus. If using only
two speakers, adjust the Fader control to the rear
speakers.
Antenna Connections
Connect an AM/FM antenna to the antenna socket
extending from the rear of the RC900BT. For
information on a suitable antenna, contact your
nearest GME branch or marine retailer.
iPod Connectivity
The RC900BT has a white lead which, when
connected with an LEO23 (optional 1.1 m lead),
enables an iPod to be connected directly to the
stereo. Limited functions of the iPod can be accessed
via the RC900BT, including the selection of albums
and songs. Access to displaying the iPod library
on the RC900BT is not available however the iPod
library and all functions can be viewed on the iPod.
Microphone
The RC900BT has a built-in microphone for
use when making and receiving phone calls via
Bluetooth. In situations where the RC900BT is
installed too far from the driver for optimal voice
pickup, an external microphone is also included
for installation closer to the driving position. The
external microphone plugs into the blue socket on
the RC900BT’s rear cable assembly.
External remote microphone mounting suggestions
ANTENNA
REAR
RIGHT
FRONT
RIGHT FRONT
LEFT
REAR
LEFT
FRONT AUDIO OUT REAR AUDIO OUT BLACK
Lch WHITE Rch RED Lch WHITE Rch RED Ipod
Mic BLUE
BLACK GREY WHITE
FRONT LEFT - WHITE/ BLACK FRONT LEFT + WHITE FRONT RIGHT + GREY REAR RIGHT + PURPLE FRONT RIGHT - GREY/ BLACK REAR RIGHT - PURPLE/ BLACK REAR LEFT + GREEN REAR LEFT - GREEN/ BLACK
