Fuse Usage
12 Passenger’s Side Headlamp
13 Fuel Pump
14 Wiper
15 Front Axle Actuator
16
Antilock Brake System (ABS), ABS
module, Four-Wheel Drive, Gravity
Sensor
17
Supplemental Inflatable Restraint
System, Sensing and Diagnostic
Module, Air Bag Off Switch
18 Heated Seat (If Equipped)
19
Cruise Control Switch, Inside
Rearview Mirror, Transfer Case
Control Module, Brake Switch,
Clutch Disable
20 Electronic Throttle Control (ETC)
21 Power Door Locks (If Equipped)
22 Injectors
23
Ignition, Clutch Starter Switch,
Neutral Safety Back-Up Switch,
Ignition Coils 1-5, Air Conditioning
Relay
24 Transmission Solenoid
Fuse Usage
25 Powertrain Control Module (PCM)
26 Back-up Lights
27
ERLS, Map Sensor, Can Purge
Solenoid
28 Rear Turn/Hazard Lights
29
Driver’s Side Rear Taillamp,
Passenger Side Air Bag Indicator
Lighting, Instrument Panel Dimming
Power (2WD/4WD Switch Lighting)
30 Powertrain Control Module (PCM) B
31 OnStar ®
32 Radio
33 Auxiliary Power 2
34 Truck Body Controller
35 Horn
36 Transfer Case Control Module
37
Turn/Hazard/Courtesy/Cargo
Lamps/Mirrors
38 Cluster
39
Rear Parking Lamp 1, Passenger’s
Side Taillamp, License Plate Lamps
5-101
