A. Windshield Washer Fluid. See “Adding Washer
Fluid” under Windshield Washer Fluid on page 5-36.
B. Coolant Recovery Tank. See Engine Coolant on
page 5-25.
C. Power Steering Fluid Reservoir (low in engine
compartment). See Power Steering Fluid on
page 5-35.
D. Transmission Fluid Dipstick. See Automatic
Transmission Fluid on page 5-19 and Manual
Transmission Fluid on page 5-22.
E. Engine Oil Dipstick. See “Checking Engine Oil”
under Engine Oil on page 5-13.
F. Brake Fluid Reservoir. See “Brake Fluid” under
Brakes on page 5-37.
G. Battery. See Battery on page 5-40.
H. Hydraulic Clutch Fluid Reservoir (If Equipped).
See Hydraulic Clutch on page 5-24.
I. Engine Air Cleaner/Filter. See Engine Air
Cleaner/Filter on page 5-18.
J. Engine Oil Fill Cap. See “When to Add Engine Oil”
under Engine Oil on page 5-13.
K. Radiator Pressure Cap. See Cooling System on
page 5-30.
L. Remote Negative (
−
) Terminal. See Jump Starting
on page 5-41.
M. Remote Positive (+) Terminal. See Jump Starting on
page 5-41.
N. Engine Compartment Fuse Block. See Engine
Compartment Fuse Block on page 5-100.
Engine Oil
Checking Engine Oil
It is a good idea to check your engine oil every time you
get fuel. In order to get an accurate reading, the oil
must be warm and the vehicle must be on level ground.
The engine oil dipstick handle is a yellow loop.
See Engine Compartment Overview on page 5-12 for
the location of the engine oil dipstick.
1. Turn off the engine and give the oil several minutes
to drain back into the oil pan. If you do not do this,
the oil dipstick might not show the actual level.
2. Pull out the dipstick and clean it with a paper towel
or cloth, then push it back in all the way. Remove it
again, keeping the tip down, and check the level.
5-13
