2. Remove the two rear
lamp assembly screws
near the tailgate latch.
3. Pull out the lamp assembly.
4. Turn the bulb socket counterclockwise to remove it
from the taillamp housing.
5. Pull the old bulb straight out from the socket.
6. Press a new bulb into the socket and turn the socket
clockwise into the taillamp housing until it is tight.
7. Reinstall the rear lamp assembly and tighten the
screws.
8. Close the tailgate.
Replacement Bulbs
Exterior Lamp Bulb Number
Center High-Mounted
Stoplamp (CHMSL)
912
Headlamp
Composite High-Beam
Composite Low-Beam
Sealed-Beam 9005
9006
H6054
Parking/Front Turn Signal/Daytime
Running Lamp (DRL)
3757A
Parking Lamp (Inboard) 3157A
Stoplamp, Rear Turn Signal,
Taillamp, and Back-Up Lamp
3057
For replacement bulbs not listed here, contact your
dealer.
5-51
