Page 539

background image

Device

Usage

SL RIDE

Ride Control Harness
Connection

HDLR 2

Headliner Wiring Connector

BODY

Body Wiring Connector

DEFOG

Rear Defogger Relay

HDLNR 1

Headliner Wiring Connector 1

SPARE RELAY

Not Used

CB SEAT

Driver and Passenger Seat
Module Circuit Breaker

CB RT DOOR

Right Power Windows Circuit
Breaker

SPARE

Not Used

INFO

Infotainment Harness
Connection

Underhood Fuse Block

The underhood fuse block in the engine compartment
on the driver’s side of the vehicle near the battery.
Lift the cover for access to the fuse/relay block.

To remove fuses hold the end of the fuse between your
thumb and index finger and pull straight out.

See Engine Compartment Overview on page 5-14 for
more information on its location.

5-127
