Galaxy Audio LA4/LA4PM - Manual (Page 6)

Frequency response: 200 Hz –15 kHz
Power handling
capacity:
125 Watts
Sensitivity: (1 watt @ 1Meter) 88 dB
Maximum SPL: (125 watts @ 1 meter): 109 dB
Speaker complement: Four 4.5-inch full range drivers
Nominal impedance: 16 ohms
Input connection:
Two Speakon®/ ¼ -inch combinations jacks wired in
parallel. Speakon® wiring (1+ Pos.) (1- Neg.)
Enclosure Materials: 15mm plywood, metal mesh grille
Color: Black
Dimensions:
21.5-inches x 7.5-inches x 8.5-inches (546 mm x 191 mm
x 215 mm)
Features: Integrated Handle and 1 3/8” Pole Mount Socket
Net weight: 14.1 lbs. (6.39 kg)
LA4
LA4 LINE ARRAY
SPECIFICATIONS
4
