3
CORE 15 & 18 CORE 15 & 18
The Core 18 Subwoofer is an unpowered 8 ohm speaker cabinet with a 18"
woofer capable of reproducing low frequencies down to 36 Hz!
The pole mount socket on the top of the cabinet fits a standard 1-3/8" stand
pole which will allow for mounting of Cores, LA4,s or other speaker cabinets
with a 1-3/8" pole mount socket, above the Core 18 creating a full range 2 or
3-way sound system with high fidelity audio and unmatched low end.
The back panel features two twist-lock plugs and a two terminal barrier strip.
The two input jacks are wired in parallel to provide a convenient way to daisy
chain multiple speakers to a single amplifier channel.
600 WATTS
IMPEDANCE: 8 OHM SER.
NO.
1+
POS 1- NEG Twist Lock ¼"
CE
18
www.galaxyaudio.com
CORE 18
FRONT BACK SIDE BOTTOM TOP
500 WATTS
IMPEDANCE: 8 OHM SER.
NO.
1+ POS 1- NEG Twist Lock ¼"
CE
15
www.galaxyaudio.com
CORE 15
FRONT BACK SIDE BOTTOM TOP
