RECORDING FROM YOUR COMPACT DISC PLAYER (EDIT)
If you wish to make a tape recording of a disc or a program, it can
be
useful
to
store
the
recording
time
of
the
tape
in
the
player’s
memory.
Should
the
disc
or
the
program
be
longer
than
one
side
of
the
tape,
a
pause
will
then
be
inserted
automatically
afterthe
lasttrack
which fits onto that side. This will prevent the disc or the program
continuing to play when the tape has already stopped.
•
Press EDIT.
>
CASSETTE
lights up with beneath it ’C 0 0 O’.
•
Press
NEXT
or
PREVIOUS
until
the
required
recording
time
appears on the display (you will see successively: ’C 30’, ’C 45’,
’C
60’,
’C
90’
and
’C120’)
orkey
inthe
recordingtime
ofthetape
using
the
’1-0’
digit
buttons.
For
a
60-minute
tape
you
should
key in ’060’.
>
The
recording
time
is
now
stored
in
the
player’s
memory;
you
can now record the disc or the program.
•
Press PLAY/REPLAY.
>
CASSETTE SIDE A
lights up, followed by
PLAY or PROGRAM
PLAY.
The
track
number
indicator
shows
which
tracks
can
be
recorded
on
side
A
of
the
tape;
these
numbers
will
be
played
one after the other.
> Play will stop after the last track.
>
CASSETTE
SIDE
B
lights
up
and
the
track
number
indicator
shows which tracks can be recorded on side B of the tape.
•
Press PAUSE.
>
The
track
numbers
shown
on
the
number
indicator
are
played
in that order.
Hotel
-
You
can
also
start
playback
with
RANDOM;
the
numbers
will
then be recorded in a different order than on the disc or in the
program.
-
As
soon
as
you
press
PLAY/REPLAY
or
RANDOM,
the
other
player
functions
(except
TIME
and
DIM)
will
temporarily
be
switched
off
to
prevent
the
recording
being
interfered
with.
EDIT ACTIVE
lights
up
if
you
press
one
of
the
other
buttons
during playback.
ADDITIONAL INFORMATION
CARE OF THE DISCS
Although
both
sides
of
a
disc
are
protected
by
a
special
coating,
it is still advisable to treat the discs with care:
•
Never
leave
discs
lying
around,
put
them
back
in
their
holders
Immediately after use.
• Never write on the printed side!
• Do not attach any stickers on the disc.
•
Keep
the
shiny
surface
of
the
disc
clean.
Use
a
soft
lint-free
cloth and always wipe the disc in a straight line from center to
edge. You may breath lightly on the disc first.
The
cleaning
set
SBC
3540
A01,
available
separately,
is
a
useful
accessory
for
cleaning
your
discs.
It
contains
a
protective
sup
port, a special disc cleaning cloth and a bottle of cleaning fluid.
If
your
local
dealer
does
not
carry
the
accessory,
it
may
be
ordered direct from Philips Consumer Electronics Company.
Call Toll Free: 1-800-255-5122
In Tennessee, Call: 1-800-824-2567
Or write:
Philips Consumer Electronics Company
Accessories Marketing Department
P.O. Box 1597
Greensville, TN 37744-9983
ImportantI
-
Cleaning
agents
for
conventional
records
are
not
suitable
for
cleaning
a
Compact
Disc.
Nor
may
detergents
or
abrasive cleaning agents be used. ____________________
PLAYER MAINTENANCE
A
chamois
leather
slightly
moistened
with
water
is
sufficient
for
cleaning
the
piayer.
Do
not
use
cleaning
agents
containing
alcohol, spirits, ammonia or abrasives.
The disc tray should be kept free of dust with a dry cloth.__________________________
TECHNICAL DATA
Typical Audio Performance
Frequency range: 2-20,000 Hz
Amplitude linearity: 0.035 dB (20-20,000 Hz)
Phase linearity: 0.2° (20-20,000 Hz)
Dynamic range: 97 dB
Signal-to-noise ratio: 100 dB (20-20,000 Hz, A weighted)
Channel separation: 100 dB (1 kHz)
Total harmonic distortion: 0.002% (1 kHz)
Wow and flutter: quartz crystal precision
D/A conversion: Bitstream conversion (256 x oversampling,
1
bit),
in
differential
mode
Audio
output
level:
2
V„ns
Impedance PHONES jack: 8-1000 ohms
Power supply
Mains voltage and frequency: see the type plate on the rear of the
player
Power consumption: 15 W approx.
Safety requirements: UL
Cabinet
Material/finish: metal and polystyrene with decorative trim
Dimensions (w x h x d) :
161%2"
X
3%''
X
m"
(420
X
90
X
280 mm)
Weight: 8.82 lbs (4 kg) approx.
Specifications are subject to change without notice
SYMPTOMS AND THEIR LIKELY CAUSES
Insufficient
familiarity
with
the
combination
of
a
new
product
and
new
discs
may
lead
to
faults
arising
during
use.
These
are
generally
caused
by
simple
errors
in
operation
or
external
factors.
It
is
perhaps
useful
to
check
the
points
listed
below
and
where
possible remedy these before taking your player for repair.
- The transit clamps have not been removed.
-
Condensation
has
formed
on
the
lens
of
the
laser
due
to
a
dramatic
change
in
temperature.
This
will
disappear
automati
cally after some time.
- There is a foreign object in the disc tray.
-
The disc has not been inserted with the printed side up orthere
is no disc in the tray.
- The disc is dirty, badly scratched or warped.
-
The
player
has
been
connected
to
the
PHONO
jack
of
the
amplifier.
If the fault remains, try to clear it by switching the player off and on.
If this also fails to help, do not continue experimenting, but remove
the plug from the outlet and consult your dealer.
Certain faults may be caused by a disc. In order to help determine
the
precise
cause,
take
the
disc
with
which
the
fault
occurred
with
you when you take the player for repair.
Under no circumstances should you repair the player yourself,
as this will invalidate the guarantee!
