8
S
PECIFICATIONS
Width: 0.79in [20mm]
Length: 0.79in [20mm]
Height: 0.39in [10mm]
Weight: 0.243oz [6.9g]
Maximum* Operating Voltage: 3.8V to 6.0V DC (Gyro only)
Current Drain: 40mA (Gyro only)
Selectable Servo Frame Rate: 70Hz, 280Hz and 560Hz
Center Pulse Width: 1520 S (70Hz & 280Hz Frame Rate)
760 S (560Hz Frame Rate)
Flight Mode: User selectable F3C or 3D
Operating Temperature: 14ºF to 113ºF
Control System: Advanced PID control
Sensor: MEMS vibrating structure gyro
Angular Velocity Range: ±800 Degrees Per Second
*The maximum operating voltage listed only applies to the GY520.
Always verify that your receiver, servos, tail rotor servo, governor, switch
and any other electronic components used in your installation are capable
of operating at the voltage you plan to use.
