20
R
EFERENCE
R
EFERENCE
Ratings
72 MHz Band: (Aircraft only)
72.010 11 72.210 21 72.410 31 72.610 41 72.810 51
72.030 12 72.230 22 72.430 32 72.630 42 72.830 52
72.050 13 72.250 23 72.450 33 72.650 43 72.850 53
72.070 14 72.270 24 72.470 34 72.670 44 72.870 54
72.090 15 72.290 25 72.490 35 72.690 45 72.890 55
72.110 16 72.310 26 72.510 36 72.710 46 72.910 56
72.130 17 72.330 27 72.530 37 72.730 47 72.930 57
72.150 18 72.350 28 72.550 38 72.750 48 72.950 58
72.170 19 72.370 29 72.570 39 72.770 49 72.970 59
72.190 20 72.390 30 72.590 40 72.790 50 72.990 60
50 MHz Band: (Aircraft/car/boat -Fcc Amateur license required)
50.800 00
50.820 01
50.840 02
50.860 03
50.880 04
*Specifications and ratings are subject to change without prior notice.
Transmitter T6YF
(2 sticks, 6 channels, FM transmitter)
Transmitting frequency: 29, 35, 36, 40, 41, 50,
60, 72, 75 MHz
Modulation method: FM(Frequency Modulation)
Power requirement: 12V(penlight battery x 8) or
9.6V nicd battery
Current drain: 180mA
Receiver R127DF
(7 channels, FM dual conversion receiver)
Receiving frequency: 50, 60, 72, 75 MHz
Intermediate frequency: 1st IF 10.7MHz, 2nd IF
455kHz
Power requirement: 6V (penlight battery x 4) or
4.8V nicd battery(common with servo)
Current drain: 10.0mA
Size: 64.3x35.8x21.0mm
Weight: 40.5g
Receiver R116FB(not for U.S.A.)
(6 channels, FM receiver)
Receiving frequency: 29, 35, 36, 40, 41, 60, 72
MHz
Intermediate frequency: 455kHz
Power requirement: 6V(penlight battery x 4) or
4.8V nicd battery(common with servo)
Current drain: 22mA
Size: 33.4x50.4x20.5mm
Weight: 30g
Servo S3003
(Standard servo)
Power requirement: 4.8V or 6V (common with
receiver)
Current drain: 8mA (idle)
Output torque: 3.2kg-cm (4.8V)
Operating speed: 0.23sec/60 degrees(4.8V)
Size: 40.4x19.8x36mm
Weight: 37.2g
Frequencies
The following frequencies and channel numbers may be used for aircraft and surface in
the United States:
50.900 05
50.920 06
50.940 07
50.960 08
50.980 09
