32
Functions
3rd channel servo (EPA) adjustment
(Preparation)
- Select setup item "3C-L.F.U" and make the following adjustments:
1
3rd channel servo (up side) adjustment
Use the (+) and (-) buttons to adjust the steering angle.
2
3rd channel servo (down side) adjustment
Select setup item "3C-R.B.D" and use the (+) and (-) buttons to adjust the
steering angle.
3
When adjusting the EPA of another channel immediately after this, see the
adjustment method for that channel. When ending adjustment, return to
the initial screen by pressing the (SEL) button.
2
Throttle (brake side/reverse side) adjustment
Push the throttle trigger fully to the brake side and use the (+) and (-) but-
tons to adjust the steering angle. However, when using an FET amp, set to
100%.
3
When adjusting the EPA of another channel immediately after this, see the
adjustment method for that channel. When ending adjustment, return to
the initial screen by pressing the (SEL) button.
