Operating Instructions and Parts Manual
www.chpower.com
AL2810
301-530
Ref. No. Description Part Number Qty.
1 Sleeve bearing 301-047 1
2 Shield front 301-189 1
3 Coupling set assembly 189-046A 1
4 Shield-rear 301-092 1
5 Spacer-tube 301-048 2
6 Washer, lock 140-035 2
7 Nut 140-051 2
8 Stud 100-328 1
9 Holder 305-013 1
10 Cog Belt 301-231 1
11 Cover-bottom 305-067 1
12 Adapter 305-012 1
13 Screw 100-339 4
14 5.5 HP Engine Assembly 301-524 1
15 Spacer tube 305-046 4
16 Clutch assembly 301-264 1
17 Cover 301-529 1
18 Holder-manifold 305-064 1
19 Plate-Gearbox mount 305-045 1
20 Sensor assembly 331-294-99 1
21 Pressure control board 301-282-99 1
22 Knob assembly 301-523A 1
23 Nut 140-044 8
24 Screw 305-047 4
25 Gearbox 301-208 1
26 Connecting rod assembly 301-333 1
27 Cover top 301-531 1
28 Grommet 301-135 6
29 Screw 100-312 4
30 Cover-Gearbox 301-320 1
31 Screw 301-337 2
32 Bolt 301-547 2
33 Lock nut 100-317 2
34 Washer 140-029 4
35 Washer 100-344 4
36 Shock mount 301-536 4
Ground assembly 188-160 1
Parts List for Power Unit Assembly
