Campbell Hausfeld QUADRAFLOW AL2810 - Manual (Page 19)

19
Operating Instructions and Parts Manual
www.chpower.com
AL2810
Ref. No. Description Part Number Qty.
1 007 Gun with swivel (Optional) 120-201XL 1
2 50’ x 1/4” Hose (Optional) 100-011 1
3 50’ x 3/8” Hose (Optional) 100-023 1
4 3/8” M x 3/8” M Nipple 169-010 1
5 Manifold filter assembly 111-200-99 1
6 3/8” plug 100-129 1
7 3/8” cap with ring 100-161 1
8 1/4” x 1/4” nipple 100-070 1
9 Ball valve 100-119 1
10 1/4” M x 1/4” F x 4’ Swivel hose 100-012 1
11 1/4” M x 1/4” f Elbow 100-004 1
12 1/4” Return tube 188-177 1
13 3/8” M x 3/8” F Elbow 169-013 2
14 3/8” F x 3/8” M x 21” Hose 100-123 2
15 1/4” M x 3/8” M Elbow 100-141 1
16 Manifold 301-253 1
17 1/4” Plug 100-028 2
18 1/4” Nut 100-317 2
19 1/4” Bolt 100-345 2
20 3/8 M x 1/4 M NPS Nipple 100-109 1
21 SL Fluid Pump 187-410 1
22 3/8 M x 3/8 M Elbow 167-016 1
Parts List for Paint System Assembly
