Performance
Switch bandwidth
Maximum frame size
Port types
Media types
Management access
Management
Availability
Security
Diagnostics
Dimensions (h x w x d)
Temperature range
Humidity range
Electrical specifications
Weight
Safety
Electromagnetic emissions
Electromagnetic immunity
1.063 Gb/sec line speed, full duplex; 2.125 Gb/sec line speed, full duplex; auto-sensing of 1 Gb/sec and 2 Gb/sec port speeds; optionally
programmable to fixed port speed; speed matching between 1 Gb/sec and 2 Gb/sec ports; aggregate bandwidth 64 Gb/sec end-to-end
Fabric latency <2.1 µsec with no contention, cut-through routing at 2 Gb/sec
64 Gb/sec end-to-end
2112-byte payload
16-ports universal, FL_Port, F_Port, and E_Port; self-discovery based on switch type (U_Port)
Small-form-factor-pluggable (SFP); short wavelength (SWL) up to .31 mi (500m), long wavelength (LWL) up to 21 mi ( 35 km); distance
depends on fiber-optic cable and port speed
10/100 Ethernet port (RJ-45); Serial port (RS-232);
Advanced Web Tools included; Fabric Manager (optional) Management access in-band via Management Server
Hot-plug redundant power supplies and fans; hot-plug optics; online diagnostics; fault-isolation tools for network-wide activity
Fabric security for configuration management, SAN access, and authentication/authorization
Diagnostics POST and embedded online/offline diagnostics
8.73 cm (1.71 in) x 42.855 cm (16.87 in) x 45.0 cm (17.72 in)
10°C to 40°C (50°F to 104°F) (operating)
-35°C to 65°C (-31°F to 147°F) (non-operating)
5% to 85% non-condensing at 40°C (104°F)
Operational: 85 to 264 VAC
12.94 kg (28.5 lbs)
EN 60950/IEC 950 Compliance (International); UL Listed, UL 60950 (USA, Canada, File E136462); TÜV GS Certificate (Germany);
CE Marking (European Union); Highly Specialized Equipment (Mexico)
USA: FCC Class A (Self Declaration); EU Countries: EN 55022 Class A; International: CISPR22 Class A; Korea: RRL Class A; Japan: VCCI
Class A; Australia/New Zealand: CISPR22 Class A; Taiwan: BSMI Class A; Russia: GOST Class A; IEC 61000-3-2: Harmonic Current;
IEC 61000-3-3: Voltage Fluctuations and Flicker
EU Countries: EN 55024 / CISPR 24 including:
EN 61000-4-2/IEC 61000-4-2: Electrostatic Discharge (ESD)
EN 61000-4-3/IEC 61000-4-3: Radiated Immunity
EN 61000-4-4/IEC 61000-4-4: Electrical Fast Transient (EFT) / Burst
EN 61000-4-5/IEC 61000-4-5: Surge
EN 61000-4-6/IEC 61000-4-6: Conducted Immunity
EN 61000-4-11/IEC 61000-4-11: Voltage Dips and Interruptions
Technical specifications
HP StorageWorks SAN Switch 2/16-EL
