Universal Control Port
Configuring the Control Port
The control port configuration is set using the dip-switch array
inside the unit. When you open the phaser, you’ll see a set of 3
dip-switches labelled ‘CON JACK CONFIG’. On power up, the
configuration will be changed to the new setting. Here’s a table
of the dip settings for the various configurations:
MODE
DIP1
DIP2
DIP3
Expression (default)
OFF
OFF
OFF
Control Voltage
ON
OFF
OFF
External Tap – Latching
OFF
ON
OFF
External Tap – Momentary
(normally open)
OFF
OFF
ON
External Tap – Momentary
(normally closed)
ON
ON
OFF
Audio Input
ON
OFF
ON
MIDI
OFF
ON
ON
