LOCATION OF CONTROLS

1

3

2

4

5

7

6

8

9 10 11 12 13 14

15 16 17

18

19

20

21 22 23 24

1. FM Lead Wire Antenna
2. Speaker Terminals (Rear of Unit)
3. CD Compartment 1
4. AC SOCKET (Rear of Unit)
5. CD Compartment 2
6. DISC SELECT Button
7. Headphones Jack
8. SLEEP/TIMER Button
9. POWER/STANDBY Button
10. REPEAT/PRESET UP Button
11. Standby Indicator
12. MEMORY/CLOCK ADJ Button

13. Remote Sensor
14. TUNING/SKIP/Search Button
15. Display
16. STOP/BAND (■) Button
17. PLAY/PAUSE (Š ) Button
18. TUNING/SKIP/Search Button
19. CD Function Button
20. TUNER Function Button
21. VOLUME Down Button
22. PRESET EQ Button
23. VOLUME Up Button
24. OPEN/CLOSE Button

FRONT
