When Wet Cutting:
• Secure the drain plug and fi ll the tray with clean water.
On Gasoline Models:
• To engage water pump loosen the black knob and
push top of water pump to the left with constant pres-
sure and tighten black knob. (Figure 9 & 12)
• Prime the pump using the priming bulb. Pump the
bulb until water fi lls the clear plastic coolant hose
from the tray to the pump.
On Electric Models:
• Plug submersible pump into the special outlet on the
motor (circled). (Figure 10)
This outlet is intended for the water
pump only pictured in (Figure 11).
Do not use it for any other purpose.
DO NOT LET THE
WATER PUMP RUN DRY.
On All Models:
• The water in the tray must be kept clean. Running dirty
water through the system will cause damage.
• To change the water, turn off the saw, remove the plug
in the bottom of the tray to drain water and dispose of
properly. Do not drain onto the surface being worked on
or other maintained surface because staining will occur.
Flush any loose grit and dirt out of the tray. Replace
drain plug and refi ll with clean water. If water fl ow to the
blade seems to be low, check that strainer is clean and
the water pump pulley is properly engaged.
Figure 10
Shows BB14E Water Pump Outlet Figure 9
• To engage water pump loosen the black knob and push
top of water pump to the left with constant pressure and
tighten black knob. (Figures 9 & 12) Use the priming bulb
shown in (Figure 13) to prime the water pump.
On Gasoline models only On Gasoline models only
Figure 11
Black knob Black knob
