Equipment Instruction Manual
EDCO POWER TROWELS
HOW TO ORDER REPAIR PARTS
To ensure product safety and reliability, always use genu-
ine EDCO replacement parts when making repairs to the
equipment.
When ordering parts, please specify the MODEL and
SERIAL NUMBER of the machine as given on the NAME-
PLATE. In addition, give part number, description and
quantity as listed on the parts list.
Please note: Due to improvements and changes in the
equipment the illustrations shown may be different from
the actual machine.
Toll Free: Voice 1-800-638-3326 • Fax 1-800-447-3326
Figure 1Figure 1
Table of Contents
Section Page Number
Specifi cations
Safety Guidelines
Before Starting Gasoline Engine
Moving The Trowel
Adjusting Blade Angle
Hoisting The Trowel
Optional Equipment
Maintenance Instructions
Lubricating The Trowel
Maintenance Schedule
SMI Dust and Silica Warning
Limited Equipment Warranty
3
4
5
6
6
6
7
8
9
10
15
16
24”
61 cm
30”
76 cm
36”
91 cm
46”
116 cm
Diameter
A
B
C
D
Weight
26”
66 cm
31”
79 cm
36 1/2”
93 cm
46”
117 cm
33”
84 cm
40”
102 cm
45”
114 cm
55”
140 cm
63”
160 cm
66”
167 cm
69”
175 cm
74”
188 cm
22 1/2”
57 cm
24”
61 cm
24”
61 cm
26 1/2”
67 cm
155 lbs
70.5 kg
170 lbs
77.3 kg
225 lbs
102.3 kg
Specifi cations & dimensions are approximate
and subject to change.
140 lbs.
63.6 kg
