TV Operations

TV tuner functions

When an optional TV tuner is connected through
the CeNET cable, this unit controls all TV tuner
functions. To watch TV requires a TV tuner and
monitor.

Watching a TV

1. Press the [Function] button and select the

TV mode.

2. Press the [Band] button to select the desired

TV band (TV1 or TV2). Each time the button
is pressed, the input selection toggles be-
tween TV1 and TV2.

3. Press the [

A] or [D] button to tune in the

desired TV station.

Tuning

There are 3 types of tuning mode available,
Seek tuning, manual tuning and preset tuning.

Seek tuning

1. Press the [Band] button and select the de-

sired TV band (TV1 or TV2).

∗ If “MANU” is lit in the display, press and hold

the [Band] button for 1 second or longer.
MANU” in the display goes off and seek tun-
ing is now available.

2. Press the [

A] or [D] button to automati-

cally seek a station. Press the [

D] button to

automatically tune up the frequency band to
the next available TV station; press the [

A]

button to automatically tune down.

TV Operations

Manual tuning

There are 2 ways available: Quick tuning and
step tuning.

When you are in the step tuning mode, the fre-
quency changes one step at a time. In the quick
tuning mode, you can quickly tune the desired
frequency.

1. Press the [Band] button and select the de-

sired band (TV1 or TV2).

∗ If “MANU” is not lit in the display, press and

hold the [Band] button for 1 second or longer.
MANU” lights in the display and manual tun-
ing is now available.

2. Tune into a station.
Quick tuning:

Press and hold the [

A] or [D] button for 1

second or longer to tune in a station.

Step tuning:

Press the [

A] or [D] button to manually

tune in a station.

Preset tuning

A total of 12 TV stations can be stored (6-TV1
and 6-TV2). This allows you to select your favor-
ite TV stations and store them in memory for
later recall.

1. Press the [Band] button and select the de-

sired TV band (TV1 or TV2).

2. Turning the [Preset] knob to select a TV sta-

tion to start with.

Manual memory

1. Press the [Band] button and select the de-

sired TV band (TV1 or TV2).

2. Press [

A] or [D] button to select a station

to be put into memory. Then, press the
[Memory] button.

3. Turning the [Preset] a preset memory num-

ber to be registered.

4. Press and hold the [Memory] button (for

about 2 seconds).

∗ After a registration is completed, “CH” indica-

tion becomes lit in the display from the blink-
ing status.

Auto store

Auto store selects 6 TV stations automatically
and stores each one into preset memory.

If there are not 6 stations with good reception,
stations previously stored in memory remain
and only the strong stations are stored into
memory.

1. Press the [Band] button and select the de-

sired TV band (TV1 or TV2).

2. Press and hold the [Scan] button for 2 sec-

onds or longer. The stations with good recep-
tion are stored automatically to the preset
channels.

Preset scan

Preset scan allows the user to view each preset
position before it automatically advances to the
next preset. This function is useful for searching
for a desired TV station in memory.

1. Press the [Scan] button.

2. When the desired station is found, press the

[Scan] button again to remain tuned to that
station.

Note:
• Do not press and hold the [Scan] button for 2

seconds or longer. Doing so will trigger the auto
store function and start storing stations into
memory.

Setting the TV diver

You can change the reception setting for the TV
antenna connected to the TV tuner.

1. Press and hold the [Title] button for 1 second or

longer to switch to the adjustment selection display.

2. Press the [

A] or [D] button to select “TV

DIVER”.

3. Turning the [Rotary] knob clockwise to “ON

or counterclockwise to “OFF”.
ON:
Sets the diver setting to ON.
OFF:
Sets the diver setting to OFF.

4. Press the [Title] button to return to the previ-

ous mode.

Setting the TV area

When you select the TV area (TV reception
area), the TV tuner area setting changes.

1. Press and hold the [Title] button for 1 second

or longer to switch to the adjustment selec-
tion display.

2. Press the [

A] or [D] button to select “TV

AREA”.

3. Press the [

s] button.

4. Turning the [Rotary] knob clockwise or coun-

terclockwise to select the reception area.

5. Press the [

s] button.

6. Press the [Title] button to return to the previ-

ous mode.

∗ The above operations are required when a TV

tuner other than TTX7501z is connected.

Watching a video

The TV tuner has a VTR input terminal to which
1 external device can be connected. Connect a
12 V video cassette player (VCP) or video cas-
sette recorder (VCR) to the TV tuner input termi-
nal.

1. Press the [Random] button to select VTR.

2. To return to the TV broadcast, press the

[Random] button.
