Getting To Know Your Compressor - Shop Air Series
Operating Instructions
figure 1 - Shop Air Series Components
Compressor Pump
Compressor Pump
Air Filter
Air Filter
Beltguard
Beltguard
Motor
Motor
Pressure Switch
Pressure Switch
Magnetic Starter
Magnetic Starter
Tank Pressure
Gauge
Check Valve
Check Valve
Discharge
Tube
Tank Pressure
Gauge
Manual Tank Drain
Manual Tank Drain
