Operating instructions – ebm-papst G3G250-MW50-01 User Manual
Page 5
Operating instructions
G3G250-MW50-01
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Cable diameter min. 4 mm, max. 10 mm, tightening torque 4±0.6 Nm
2
Depth of screw 10-12 mm, tightening torque 20±3 Nm
3
Tightening torque 3.5±0.5 Nm
Item no. 50734-5-9970 · Revision 82547 · Release 2014-05-08 · Page 5 / 14
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · D-74673 Mulfingen · Phone +49 (0) 7938 81-0 · Fax +49 (0) 7938 81-110 · [email protected] · www.ebmpapst.com
