Operating instructions
R2E180-AH05-06
Translation of the original operating instructions
4.4 Connection screen
U1
blue
U2
black
Z
brown
Item no. 10129-5-9970 · Revision 82598 · Release 2014-05-13 · Page 7 / 9
