Operating instructions R2E180-AH05-06
Translation of the original operating instructions
3.2 Nominal data
Motor M2E068-DF
Phase 1~ 1~
Nominal voltage / VAC 230 230
Frequency / Hz 50 60
Type of data definition fa fa
Valid for approval /
standard CE CE
Speed / min -1 2600 2850
Power input / W 115 155
Current draw / A 0.51 0.68
Motor capacitor / µF 3 3
Capacitor voltage / VDB 400 400
Min. back pressure / Pa 0 0
Min. ambient temperature
/ °C -25 -25
Max. ambient
temperature
/ °C 100 95
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Technical features
Mass 3.1 kg
Size 180 mm
Surface of rotor Uncoated
Motor suspension Motor mounted via brackets on one side
Direction of rotation Counter-clockwise, seen on rotor
Type of protection IP 00
Insulation class "F"
Humidity class F0
Mounting position Shaft horizontal
Condensate discharge
holes None
Operation mode S1
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) < 0.75 mA
Electrical leads Via terminal strip
Cable exit Axial
Protection class I (if protective earth is connected by
customer at the connection point of the
housing)
Approval EAC
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.4 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.5 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
