Operating instructions – ebm-papst R2E180-AH05-06 User Manual
Page 4
Operating instructions
R2E180-AH05-06
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Centrifugal impeller (sheet steel, galvanised)
2
Centrifugal impeller (sheet steel, rust-resistant and acid-resistant)
3.1
L (blue)
3.2
Z (brown)
3.3
N (black)
4
M4 screw for fastening earth conductor
Screw depth max. 5 mm
Item no. 10129-5-9970 · Revision 82598 · Release 2014-05-13 · Page 4 / 9
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · D-74673 Mulfingen · Phone +49 (0) 7938 81-0 · Fax +49 (0) 7938 81-110 · [email protected] · www.ebmpapst.com
