Operating instructions
G4D225-FK10-03
Translation of the original operating instructions
4.4 Connection screen
Δ
Star connection
L1
= U1 = black
L2
= V1 = blue
L3
= W1 = brown
TOP
2 x grey
PE
green/yellow
Item no. 11992-5-9970 · Revision 82513 · Release 2014-05-08 · Page 8 / 10
