Operating instructions
G4D225-FK10-03
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Connection line silicone 6G 0.5 mm², 6 x brass lead tips crimped
Item no. 11992-5-9970 · Revision 82513 · Release 2014-05-08 · Page 4 / 10
