EI-1000/EI-2000/EI-4000 ROUTING TICKET
SO # DATE:
PROGRAM: SERIAL NUM:
VER: BOARD REVISION :
CH1 (LEFT) SCALE: CH2 (RIGHT) SCALE:
CH1 (LEFT) FULL SCALE: CH2 (RIGHT) FULL SCALE:
CH1 (LEFT) SCALE SN: CH2 (RIGHT) SCALE SN:
CH3 SCALE: CH4 SCALE:
CH3 FULL SCALE: CH4 FULL SCALE:
CH3 SCALE SN: CH4 SCALE SN:
SETUP
OPERATION P001 SET POINT MODE #1 P500
lb/kg P010 SET POINT MODE #2 P501
USED P020 ANALOG OUTPUT SEL P600
TARE LOCK P030 BAUD RATE P701
FRONT PANEL ACCESS P999
CHANNEL SETUP
SCALE SEL P100 P200 P300 P400
FULL-SCALE P110 P210 P310 P410
RESOLUTION P111 P211 P311 P411
AVERAGE P112 P212 P312 P412
AUTO-ZERO P113 P213 P313 P413
PUSH TO ZERO P114 P214 P314 P414
THRESHOLD P116 P216 P316 P416
START P117 P217 P317 P417
SET POINT #1 P510 P520 P530 P540
SET POINT #2 P511 P521 P531 P541
ANALOG F.S. P610 P620 P630 P640
ZERO CAL 1.o 2.o 3.o 4.o
SPAN CAL 1.c 2.c 3.c 4.c
S1 DIP SWTICH
-1 -2 -3 -4
SENSE
ENABLE J1/J2 DISABLE
EI-2000 J3 EI-1000
TECH_______
S2 V. SEL.
115V
230V
OPTIONS
RTC
EI-2000-I/O
EI-2000-EXP
RELAYS
EI-4000
