Eagle Microsystems WT3600 User Manual

Page 8

Text mode
Original mode

SECTION 5.0 SPECIFICATIONS

CONSTRUCTION:

Load Cell: Stainless Steel
Trunnion Castings: Aluminum
Axles & Hardware: Stainless Steel
Rollers: UHMW Plastic
Shock Pads: Fabcel 300 ®
Conduit & Fittings: PVC
Junction Box: Cast Iron

FINISH:

Trunnion Castings: Acrylic Paint
Junction Box: Clear Acrylic Paint

CAPACITY:

4000 Lb

SAFE OVERLOAD:

200% of Rated Capacity.

ULTIMATE OVERLOAD:

300% of Rated Capacity.

NOMINAL OUTPUT:

0.5 mV/V at full scale

EXCITATION VOLTAGE:

5 to 15 VDC

OPERATING ACCURACY:

0.5% of Capacity.

REPEATABILITY:

0.2% of Capacity.

LOAD CELL:

Stainless Steel strain gage, hermetically sealed,1000

Ω

TEMPERATURE:

0 to 150 Degr. F.

HOOK-UP CABLE:

15' of 4 conductor, color coded,shielded cable. PVC jacket.

SECTION 6.0 SPARE PARTS LIST

PART DESCRIPTION

MODEL/CAPACITY

Load Cell

TH-CM / 4,000 lbs F.S.

Roller

M10246

Roller Retaining Ring

WST-75

Shock Plate

M10250

Shock Pad

M10249

Shock Disk

M10131

Load cell Summing Board

WTSJB
