-3-
2.0 SPECIFICATIONS
Performance
Compliance
DVI v1.0, HDMI, HDCP
Maximum Pixel Clock Frequency Up to 225 MHz
Maximum Bit Rate Up to 2.25 Gbps
Supported HDTV Resolutions 480p, 720p, 1080i, 1080p, (8-bit and 12-bit color)
Supported PC Resolutions Up to 1920x1200 and 2048x1080
Input Signal Equalization Adaptive equalization, provides up to +40 dB correction @ 825 MHz
Cable Equalization Modes
Auto EQ Mode - for cable lengths up to 30 meters
Manual EQ Mode - for cable lengths longer than 30 meters
Connections
Input / Output
2x DVI 29-pin female connectors
Power Input 1x 5.5 / 2.5 mm locking connector
Cable Length
Maximum Input Cable Length
200 ft. (~ 60 meters) 1,2
Maximum Output Cable Length 15 ft. (~ 5 meters) 1
DDC Support
EDID / HDCP Support
Yes, pass-through
Mechanical
Construction
Rugged steel enclosure with durable black finish
Dimensions (H-W-D) 1.1” x 2.1” x 2.6” (29.2 mm x 53.7 mm x 67.1 mm)
Weight 4.7 oz (132 g)
Environmental
Operating Temperature
+32° to +122° F (0° to +50° C)
Storage Temperature -4° to +158° F (-20° to +70° C)
Humidity (storage / operating) 10% to 90% (non-condensing)
Power Requirements
External AC Power Adapter
Input: 100~240VAC / 50-60Hz Output: 5VDC, 3.0A
Power Consumption (typical) 1.5 watts
Regulatory Approvals
ACE™ Unit
FCC, CE, and RoHS
External AC Power Adapter FCC, CE, UL, C-UL, CEC, GS, PSE, RoHS
Warranty
Limited Warranty
1 Year Parts and Labor
Model Number
DVI-7171c
DVI Single-Link Active Cable Extender
Accessories
Included
1x External AC Power Adapter, 1x User Guide
Optional International AC Power Adapter (USA, Euro, UK, Australia)
Note 1: Maximum cable lengths using DVIGear’s 22AWG Super High Resolution (SHR™) cables.
Note 2: The maximum cable length with 1080p / 60Hz 8-bit color (1.5 Gbps.) input signal is
200 ft. (~ 60 meters). The maximum cable length with 1080p / 60Hz 12-bit color (2.25 Gbps.)
input signal is 131 ft. (~ 40 meters).
