FLIGHT MODES
TROUBLESHOOTING
PROBLEM: The quadcopter will not respond to the radio.
SOLUTION: (1) Charge or change the battery on the quadcopter. (2) Turn off
the radio and disconnect the battery for the Ominus. Re-link the
quadcopter and radio.
PROBLEM: Red radio LED light flashing after linking.
SOLUTION: Replace with new AAA batteries.
PROBLEM: Unable to flip.
SOLUTION: Battery voltage too low.
PROBLEM: Gyro not working properly.
SOLUTION: (1) Battery voltage low. (2) Re-link. (3) Land onto the ground for 3
seconds and take off again.
PROBLEM: Will not take off.
SOLUTION: Rotor blades incorrectly installed. See Rotor Blade Replacement
section.
PROBLEM: Quadcopter is shaking.
SOLUTION: Check the canopy, chassis, motors and rotor blades for damage.
If the quadcopter is constantly drifting in the same direction or a new flight control board has been installed, the sensors on the Ominus should be calibrated.
1. Center all the trim adjustments. To check the trim, push the trim button once on one side and then once on the opposite side. When the trim is centered,
the transmitter will emit a long, low pitched beep. The transmitter will emit a short beep of lower pitch as the adjustment gets closer to center and higher
pitch as the adjustment moves away from center. Continue pressing the trim button that has the lower pitch until the adjustment is centered.
2. Link the quadcopter and the transmitter.
3. Push down on the right stick and hold it. The radio will steadily beep while the stick is held down.
4. Press down on the left stick 3 times within 2 seconds. The radio will stop the steady beep and make a short beep when the stick is pressed the third time.
5. Release both sticks and push up on the throttle trim button. The red LED will flash slowly and become steady again when the calibration is complete.
6. Press down on the left stick to save the settings.
QUADCOPTER SENSOR CALIBRATION
LOW BATTERY INDICATOR
The LEDs on the Ominus will flash slowly when the battery voltage is low. The Ominus should land as soon as possible to avoid damaging the battery. Always
unplug the battery after flight. The battery needs to be charged before the quadcopter is stored.
Control sensitivity (Dual Rates) can be changed by pushing down on the right stick. The controller will
make a short, low-pitched beep when changing to low rates. This mode should be used when flying
indoors or if the pilot is not familiar with how the quadcopter responds to the controller. The controller
will make a short, high-pitched beep when changing to high rates. This mode should be used when flying
outdoors or when more agility is desired.
F- Mode LED off – Low Rates
F-Mode LED on – High Rates
The low rate sensitivity of the controls is about 25% less than the high rate sensitivity. The overall controls
can also be adjusted by
1. Holding down the right stick until the controller starts beeping.
2. Continue holding down the right stick and advance the throttle to the desired setting.
3. Release the right and return the throttle to 0%.
The default setting is when the throttle is at 50% (midstick).
To toggle between the normal and expert agility modes, press the F-Mode Button. When the accelerometers
are off, the flight controller will make the Ominus more agile, but also it is easier to crash.
F-Mode LED steady (off or on) – Normal Mode, accelerometers on
F-Mode LED flashing – Expert Mode, accelerometers off
Change control sensitivity (dual rates).
Push down on right stick and release.
Audible low and high tone.
FLIGHT MODES (F-MODE)
Easy OFF OFF
Normal ON OFF
Expert Flashing ON
Advanced Flashing ON
F-Mode F-Mode LED F-Mode Button
ON Low Tone
ON High Tone
Flashing High Tone
Flashing Low Tone
Quad LED Tx Sound
The Ominus has a receiver that is compatible with other SLT transmitters like the Tactic ™ TTX650. Not all functions like the ability to turn off the accelerometers
are available, but if the feel of a traditional transmitter is preferred, this is certainly an option.
TTX650 Setup
Model Type: Heli with H1 swashplate
Servo Reversing: All Channels Normal
Servo Travel: 125%/125% Ch. 1-3, 100%/100% Ch. 4-6
Dual Rates: 50%/125% Aileron & Elevator
Expo: -20/+100 Aileron & Elevator
Throttle Curve: 0,18,45,73,100
Gyro: 25%/75%/125%
SLT COMPATIBILITY
•
Use a trainer switch for the dual rate/expo settings.
• The high rates are used for flipping.
•
The gyro settings are used to adjust control sensitivity.
