Dromida Kodo Quick Start User Manual
Radio controlled quadcopter, Radio preparing to fly, Charging

2
1
3
4
RADIO
PREPARING TO FLY
1. Turn on the radio with throttle at lowest position.
2. Place the Kodo on a level surface and connect
the battery. The Kodo will beep twice. Do not
move the Kodo until the LEDs stop flashing.
3. Move the throttle up and listen for one beep.
4. Move the throttle down. Listen for one beep and
verify that the LEDs have stopped flashing.
The motors are armed and the KODO is ready to fly.
CHARGING
• NEVER leave the battery unattended while charging.
• DO NOT allow the USB port to power down while the charger is connected to the battery.
• ALWAYS unplug the charger from the USB port and the battery when charging is complete.
Plug charger into USB port or AC adapter (not included) as shown and connect the battery.
The red LED will flash slowly while the battery is
charging. The LED will be steady when the
battery is fully charged.
Radio Controlled Quadcopter
™
Radio
2G Memory Card
USB Card
Reader
Rotor Blade Guards
AAA Batteries (2)
USB Charge Cord
Spare Blades
(2 black, 2 white)
Flight Battery
KODO Quadcopter
Push down on the left stick to change
the sensitivity of the controls.
SENSITIVITY ADJUSTMENT
Lowest (Default)
Moderate
Maximum
x2
x3
2
3
Before taking first flight, download complete KODO
instruction manual from www.dromida.com.
NOTE: For Mode 1 configuration, refer to the complete KODO instruction manual at dromida.com
Mode 1/ Mode 2
Switch
LED
Rudder
Trim
Button
Video
Button
Aileron
Trim
Throttle/Rudder
Stick
Throttle
Trim
ON/OFF Elevator
Trim
Aileron/Elevator
Stick
