13. ESC INSTALLATION

Clean both the bottom of ESC and chassis with
alcohol. Using double sided tape, attach ESC to
chassis as shown. Connect the ESC to the motor.
Refer to the ESC instructions for setting up ESC.

14. RECEIVER INSTALLATION

Clean both the bottom of the receiver and the chassis brace with
alcohol. Install the receiver onto the upper chassis brace using
double-sided tape. Plug ESC into CH2 and servo into CH1 of the
receiver. Route the antenna wire through the antenna mount and
reinstall the antenna tube.

15. BINDING PROCEDURE

The receiver included with the Brushless Speed Kit is designed to work with the Dromida
D100 transmitter. The receiver MUST be bound to the transmitter before running the vehicle.

1. Turn on the transmitter.
2. Turn on the receiver.
3. Press and release the “BIND” button on the receiver.

At this point, the receiver should be bound to the transmitter.

We try very hard to have accurate and up-to-date information in this document. Any errors are unintentional.

dromida.com

16. TRIMMING

Throttle Trim
• If the vehicle rolls forward without throttle input, rotate the throttle trim knob slightly left.
• If the vehicle rolls backwards without throttle input, rotate the throttle trim knob slightly right.

Steering Trim
• If the vehicle tracks right (when viewed from behind), rotate the steering trim knob slightly left.
• If the vehicle tracks left (when viewed from behind), rotate the steering trim knob slightly right.
• Check that the servo saver screw is fully tightened to ensure that your vehicle tracks straight.
