MODULE INSTALLATION CONTINUED...

Tip:

,

This is only necessary if you purchase additional modules for a rack you already own. Each module will

have specific installation instructions, the following serves as an example.

STEP 1. Organize all the loot:

Confirm you have (as numbered in the previous photo ops):

1. DAC-ST board with rear panel

2. DAC-ST front panel

3. Four #6-32 x 3/8” pan head stainless steel machine screws (board to chassis)

4. Four #4-40 x 1/4” flat head stainless steel machine screws (preexisting front panel to chassis)

5. Four #6-32 x 1/4” flat head black stainless machine screws (preexisting rear panel to chassis)

6. Two 12 pin smaller flat ribbon cables

7. One 20 pin larger IDC ribbon cable

8. The A.S.S. Rack

9. Blank panel in front and back

10. Power supply (preexisting from your original Additional Switching System®)

Tip:

,

Now is not the time to start drinking. Wait until you have this bad boy assembled to celebrate.

STEP 2. Preparation

Ensure that the unit is powered down and NOT plugged into the wall. Go grab a #2 and #1
phillips screwdriver from your tool box.

Discharge any static electricity you may have picked up by touching a metal chair or table

STEP 3. Removing the lid and front and rear blank panels

•Using a #2 phillips head screwdriver (not supplied), carefully first remove the 8 black screws
securing the lid (14).

•Using a #1 phillips head screwdriver, remove the four #4-40 x 1/4” silver screws in the blank face
plate (9).
