Connector Pin-Outs
All of the XLR connectors are wired pin 2 high, pin 3 low, and pin 1 shield.
Due to back panel space limitations, we were forced to use ‘D’ connectors conforming to
the Tascam standard for the main audio input wiring (sorry). Actually, this makes wiring
the LT into a modern patchbay very easy as most of the other manufacturers use the same
standard. Those that don’t get verbal abuse at AES conventions.
‘D’ connector pin out
pin # Channel signal
1 8 high
14 8 low
2 8 shield
15 7 high
3 7 low
16 7 shield
4 6 high
17 6 low
5 6 shield
18 5 high
6 5 low
19 5 shield
7 4 high
20 4 low
8 4 shield
21 3 high
9 3 low
22 3 shield
10 2 high
23 2 low
11 2 shield
24 1 high
12 1 low
25 1 shield
13 not used
The AC Mains cable
The mains cable uses a standard IEC connector. Please use pre wired AC cables
for this device unless a technically qualified person makes the connections to a
mains plug. In this case, use only high quality mains plugs like Hubbel, Thomas & Betts,
or a similar type. Remember, in America, Black is hot, White is neutral, and Green is
ground. In Europe, Brown is hot, Blue is Neutral, and Green with a Yellow stripe is
ground. It is critical to get this correct. Double check that it is!
