SPECIFICATIONS
Nominal amplifier power [class]: 500 WRMS [class D]
Input type: Balanced XLR
Input Impedance: 23k ohm
Output (satellite) impedance: 280 ohm
Sensitivity 0.775 V (0 dBu)
Electronic crossover: 24 dB/octave, Linkwitz-Riley, 100 Hz
On-axis Frequency Range F : 43 Hz - 135 Hz
Rated maximum Peak SPL at 1 m: 131 dB
Nominal -6 dB Beamwidths:
(100 Hz, 1 oct) 360° Horizontal x 360° Vertical
Enclosure Material: MDF wood
Colour: Black
Transducers/Replacement Parts: 18H/GM 18G
AC Power Requirements: 115 V, 50 Hz/60 Hz
230 V, 50 Hz/60 Hz
Current consumption:
(Results for 230V. Double the ratings for 115V) Maximum power: 1,5A; 1/3 power: 0,4A;
1/8 power: 0,2A; idle: 0,1A
Heat Emission in BTU/h:
(1 BTU = 3.99 kcal) Maximum power: 1000; 1/3 power: 300;
1/8 power: 120; idle: 80
Dimensions (H x W x D): 64 x 55 x 53 cm (25.5 x 22 x 21 in)
Weight: 42.7 kg (94 lbs)
Shipping Weight: 45.7 kg (101 lbs)
Accessories (optional): TRD-4, cylindrical support for top boxes
F As per IEC 268-5 (1989), re. a one octave band centred at 80 Hz. Half space anechoic. Electro-acoustical. Acoustical -10 dB point is 32 Hz.
Product improvement through research and technology is a continuous process at D.A.S. Audio. All specifications subject to change without notice.
Architectural Specifications, detailed specification sheets, as well as data for EASE and other electro-acoustic prediction tools are available from
http://www.dasaudio.com/.
