HEADPHONE SYSTEM
Method 1 Seperate cue mix
A external cue mix may be feed into the AUX analog input, the internal headphone amp system can
be used
HEADPHONE
CUE MIX
Aux Analog input
Headphone output
on headphone jack
Talk back mic
Headphone output contains, the cue mix
and the talk back mic
To set this up select the PHONES / SHIFT button. When in this mode select the
“phones / aux” button (this is the phones source), then adjust the phones level
with the big knob. After setting the level leave the PHONES / SHIFT mode by
touching its button a second time. The phones level will not be effected by the
main level.
The internal headphone amp is capable of driving multiple headphones and in
many cases an external headphone amplifier is not needed.
AVOCET MAIN UNIT
