Crane Song AVOCET II - Manual (Page 25)

REV 5 pcb
Do not change jumpers or adjust the trim pots unless you are sure of what you are doing
JUMPER ON THESE 2 METER = INPUT
DE-
FAUL
T
JUMPER ON THESE 2 METER = OUTPUT
JUMPER ON = STEREO, OFF = SURROUND OPERA
TION
JUMPER ON SOLO =
ANA1 INPUT
JUMPER OFF SOLO = DA
W INPUT
JUMPER FOR HIGH GAIN ON
ANALOG 2
DEF
AUL
T
IS OFF LOW GAIN
JUMPERS FOR SURROUND OFF OFF - LEFT
, RIGHT
ON OFF - SURR
OUND LEFT
, RIGHT
OFF ON - CENTER REV 5 AND UP ONL
Y
ON ON - EXTRA
NOT
ASSIGNED
25
