Clarke BOOST 28 - Manual (Page 17)

EN ENGLISH
Clarke ® Operator's Manual (EN) - BOOST 28 - 17 -
Figure 21
WARNING: Water solutions or cleaning
materials used with this type of
machine can leave wet areas on
the floor surface. These areas
can cause a dangerous condition
for the operator or other persons.
Always put CAUTION signs near
the area you are cleaning.
WARNING: Machines can ignite flammable
materials and vapors. Do not use
with or near flammables such as
gasoline, grain dust, solvents and
thinners. Only use a cleaning
concentration recommended by
the chemical manufacturer.
WARNING: Clarke recommends a maximum
water temperature of 120 o F (49 o C).
Operating The Machine
NOTE: Put the machine in the lowest traverse speed
setting. Use the machine in an area that has no
furniture or objects until you can do the following:
1. Move the machine in a straight direction, forward
and backward.
2. Stop the machine safely.
3. Turn the machine both left and right and return to a
straight direction.
To move the machine, follow this procedure:
1. Release the parking brake (if equipped with
machine).
2. Turn the key switch to the "ON" position
3. Raise the brush.
4. Raise the squeegee.
5. When either the left or right forward/reverse
switches (figure 21, item A) are pushed in, the
machine will go forward.
6. Control the speed of traverse by using the traverse
speed control knob (figure 21, Item C).
7. To stop, release the forward/reverse switch.
8. To reverse the machine, push in the white reverse
switch (figure 21 item B) and either the right or left
forward/reverse switch (figure 21 item A) at the
same time.
9. To stop, release the forward/reverse switch.
10. To turn the machine, push the rear of the machine
to the side.
11. When you stop the machine, turn the key switch
"OFF", remove the key and set the parking brake (if
equipped).
How To Operate The Machine
A
B
C
A
