Pre-Installation
Advice
WARNING - INCORRECT FITTING OR POSITIONING
OF THIS SAFETY BARRIER CAN BE DANGEROUS
If this gate needs to be fitted to a round shaped
newel post, ‘Y’ shaped spindles are available
separately which replace the standard spidles
and wall cups supplied with this gate
Fixing surfaces must be suitable for the
purpose and structurally sound.
LOW PRESSURE MOUNTING WITH
SCREW MOUNTED WALL CUPS
ON BOTH SIDES
LOW PRESSURE MOUNTING WITH
ADHESIVE MOUNTED WALL CUPS
ON BOTH SIDES
EXTENSIONS REQUIRED
GAP
82 - 89cm
89 - 96cm
96 - 100cm
100 - 107cm
107 - 114cm
114 - 118cm
118 - 125cm
125 - 132cm
7cm
1
2
1
1
18cm
1
1
2
1
7+18cm
1
1
2
The surfaces to which the gate fits should
be completely flat and a minimum of
5cm wide.
This product may require the purchase of
appropriate fixing aids suitable for the
surface to which the wall cups are to be
fitted.
WARNING - NEVER USE WITHOUT WALL CUPS.
Without extensions, this gate is suitable for openings between 73cm (28¾in) and 82cm
(32¼in) wide. If gap is wider, see extension guide below. If necessary, fit the extension(s) first,
then follow the installation instructions (Section D).
Two 7cm extensions are included, 18cm extensions are available separately.
WARNING -
GATE MUST BE FITTED
UPRIGHT AS SHOWN
IN ORDER FOR THE
SWING CLOSE
MECHANISM TO
FUNCTION
CORRECTLY.
WARNING - WHEN FITTING ON A
STAIRWAY ALWAYS BLOCK ONE
OPENING DIRECTION SO THAT THE
GATE WILL ONLY OPEN AWAY FROM
THE STAIRS (see installation instructions).
