Cavity

Cartridge Fuse

Mini Fuse

Description

18

40 Amp Green

Auto Shutdown (ASD) Relay

19

20 Amp Yellow

Audio Amplifier – If Equipped

20

15 Amp Lt. Blue Radio

21

10 Amp Red

Siren – If Equipped

22

10 Amp Red

Ignition Run – Climate Controls/Hot Cup-
holder – If Equipped

23

15 Amp Lt. Blue Auto Shutdown (ASD) Relay 3

24

25 Amp Natural Sunroof – If Equipped

25

10 Amp Red

Ignition Run — Heated Mirrors - If Equipped

26

15 Amp Lt. Blue Auto Shutdown (ASD) Relay 2

27

10 Amp Red

Ignition Run – Occupant Classification
Module (OCM)/Occupant Restraint Con-
troller (ORC)

28

10 Amp Red

Ignition Run — Occupant Classification
Module (OCM)/Occupant Restraint Con-
troller (ORC)

29

Hot Car (No Fuse Required)

30

20 Amp Yellow

Ignition Run – Heated Seats – If Equipped

31

Spare

32

30 Amp Pink

Auto Shutdown (ASD) Relay 1

33

10 Amp Red

Switch Bank/Diagnostic Link Connector/
Powertrain Control Module (PCM)

34

30 Amp Pink

Anti-Lock Brakes (ABS) Module – If
Equipped/Electronic Stability Control
(ESC) Module – If Equipped

35

40 Amp Green

Anti-Lock Brakes (ABS) Module – If
Equipped/Electronic Stability Control
(ESC) Module – If Equipped

36

30 Amp Pink

Passenger Door Module (PDM)/Driver
Door Module (DDM)

37

25 Amp Natural Power Top Module – If Equipped

CAUTION!

When installing the integrated power module cover, it is important to ensure the cover is
properly positioned and fully latched. Failure to do so may allow water to get into the
integrated power module, and possibly result in a electrical system failure.

When replacing a blown fuse, it is important to use only a fuse having the correct
amperage rating. The use of a fuse with a rating other than indicated may result in a
dangerous electrical system overload. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be corrected.
