section. This center contains cartridge fuses and mini-
fuses. A label that identifies each component may be
printed or embossed on the inside of the cover.
CAUTION!
• When installing the Totally Integrated Power
Module cover, it is important to ensure the cover is
properly positioned and fully latched. Failure to
do so may allow water to get into the Integrated
Power Module, and possibly result in a electrical
system failure.
• When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system over-
load. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be
corrected.
The numbers inside the TIPM cover correspond to the
following table.
FUSES/TIPM
Cavity
Cartridge
Fuse
Mini-
Fuse
Description
J1 40 Amp
Green — Power Folding Seat
J2 30 Amp
Pink — Power Liftgate
Module
J3 30 Amp
Pink — Rear Door Module
(RR Door Node)
J4 25 Amp
Natural — Driver Door Node
J5 25 Amp
Natural — Passenger Door
Node
J6 40 Amp
Green — Anti-Lock Brake
System (ABS)
Pump/ESP
474 MAINTAINING YOUR VEHICLE
