Cavity
Cartridge
Fuse
Mini-Fuse Description
15 50 Amp Red RAD Fan
Relay
Battery Feed
16 15 Amp Lt.
Blue IGN Run/
Acc Cigar
Ltr/Sunroof
17 10 Amp Red IOD Feed
CVT Mod/
Mod_Wcm
18 40 Amp
Green ASD Relay
Contact
Feed
19 20 Amp
Yellow PWR Amp
1 & Amp 2
Feed
20 15 Amp Lt.
Blue IOD Feed
Radio
Cavity
Cartridge
Fuse
Mini-Fuse Description
21 10 Amp Red IOD Feed
Intrus
Mod/Siren
22 10 Amp Red IGN RUN
Hvac/
Compass
Sensor
23 15 Amp Lt.
Blue ENG ASD
Relay Feed
3
24 25 Amp
Natural PWR
Sunroof
Feed
25 10 Amp Red Heated
Mirror
342 MAINTAINING YOUR VEHICLE
