Cavity

Cartridge

Fuse

Mini-Fuse

Description

3

10 Amp Red CHMSL

Brake
Switch Feed

4

10 Amp Red Ignition

Switch Feed

5

20 Amp
Yellow

Trailer Tow

6

10 Amp Red IOD Sw/

Pwr Mir/
Ocm
Steering
Cntrl Sdar/
Hfm

7

30 Amp
Green

IOD Sense1

8

30 Amp
Green

IOD Sense2

Cavity

Cartridge

Fuse

Mini-Fuse

Description

9

40 Amp
Green

Power Seats

10

20 Amp
Yellow

CCN Feed,
Power
Locks

11

15 Amp Lt
Blue

Power
Outlet

12

20 Amp
Yellow

Ign Run/
Acc Inverter

13

20 Amp
Yellow

Pwr Run/
Acc Outlet
RR

14

10 Amp Red IOD CCN/

Interior
Lighting

7

MAINTAINING YOUR VEHICLE

341
