Automatic Temperature Control
AUToMATic oPErATion
• Turn the mode control to the AUTo position and the blower
control to either Lo AUTo or HigH AUTo position.
• Select the desired temperature by rotating the temperature control
for either driver or passenger.
• The system will maintain the set temperature automatically.
Air condiTioning (A/c)
• if the air conditioning button is pressed while in the AUTo mode,
the indicator light may flash three times to indicate the air
conditioning is being controlled automatically.
Air rEcircULATion
• Use recirculation for maximum A/c operation.
• For window defogging, push the air recirculation off.
• if the recirculation button is pressed while in the AUTo mode,
the indicator light may flash three times to indicate the cabin air
is being controlled automatically.
uconnect
™
®®®phone
• uconnect ™ ® phone allows pairing a cellular phone equipped with
the Bluetooth ® ® Hands-Free Profile, version 0.96 or higher. See the
www.chrysler.com/uconnect website for supported phones.
refer to your owner’s Manual for further information.
Universal Consumer Interface – iPod
®
®
• An iPod ® can be plugged into the vehicle’s audio system, using the
provided cable, through a connector located in the glove box.
refer to owner’s Manual for operation.
Rotate
Mode
Control
Rotate
Passenger
Temp.
Control
Rotate
Driver Temp.
Control
Push
Air Recirc.
Button
Rotate
Blower
Control
Push Rear
Window
Defroster
Button
Push
A/C
Button
