CyberResearch GFC 1716A User Manual

Page 9

KVM Switches

KVM User x System Configuration

1 x 16

Number of PCs per KVM Switch

16 PCs

Additional Features

Hot pluggable KVM switch allows you to add or
remove PC connections without powering down
the KVM switch

Keyboard 'Hot Key' Commands for switching
channels, banks, and OSD commands

Front handle folds down for lower rack-
protrusion profile

Cables & Connectors

Number of Connectors

Connector Type

HD-15 (VGA standard)

Connector Gender

Female (socket)

Connector Details

KVM set connector on KVM side is special 15-pin
connector that incorporates the keyboard and
mouse signals. There is only 1 connector per
channel on the KVM side.

Video/KVM
Connectors

Cabling Details

Using a GFA 16CBLxx cable, on the PC side
there is a regular complement of VGA, mouse,
and keyboard male connectors.

Power

Chassis Power Input Connector

NEMA standard male PC cord socket

Indicators, Switches, & Controls

On Screen Display (OSD) Control Functions

Brightness
Contrast
RGB color adjustments
Horizontal position
Vertical position
Horizontal size
Vertical size
Color balance
Color temperature adjustment
Video source selection
Select language for OSD controls
Position of OSD controls
Reset to factory defaults
Geometry (convex/concave sides)
Geometry (parallelogram)
Phase adjustment
Auto adjustment
Recall (last OSD setting)

LCD Display On/Off Switch

Yes

OSD Controls

OSD controls for menu navigation (3 buttons)

Brightness Via

OSD

controls

Front Panel
Controls

Contrast Via

OSD

controls

Rear Panel
Controls

Power On/Off Switch

1 on/off switch

Power On/Off

LED indicates power on

System in Sleep Mode

Shown by change in LED color

Channel Number

Active channel shown by 16 LEDs

Indicators

Buzzer for Alarms

Yes
