On Screen Display for KVM Operation
When you press the OSD menu button or you use the hot key, the following window appears
on your monitor.
a. The 1 ST line bar is Bank no.
SYSTEM 06 06 Ɓ SYSTEM 05 05
Ɓ SYSTEM 04 04 Ɓ SYSTEM 03 03
ƁSYSTEM 02 ( 02 SYSTEM 01 01
BANK : 1
b. The 2 nd block is your PC
system name list. You will find the
system number list from 01 to
08.
You can define your PC name in a
maximum of 8 characters. The
factory default names for all ports
is “SYSTEM 01”, to “SYSTEM
08“.
Also, the sun symbol “ Ɓ
“ near the PC name represents
the PC system is powered on.
Ɓ SYSTEM 08 08 SYSTEM 07 07
To use up arrow key “ y “ or down arrow key “ z “ to select port for destination PC name. After
you have selected the PC port already, you can press the ENTER Key to switch the PC port
you want immediately
©/ª: SELECT PORT
To use “ PgUp “ key or “ PgDn” key for selecting previous or next Bank no. (or Box No.)
PgDn/PgUp: BANK SELECT
To press “ INS” key for editing PC name. After finishing the edit, please press “ Enter “ key for
saving information.
TAB : NEXT INSERT :EDIT
ESC : QUIT ENTER :COMPLETE
