Cable Diagrams
PS/2 Cable:
Mini Din 6 pin Male to Male
VGA Cable:
HDB15 pin Male to Male
AT to PS/2 keyboard adapter: (Optional)
Din 5 pin Male to Mini Din 6 pin Female
PS2 to DB9 adapter (Optional)
Mini Din 6 pin Female to DB 9 pin Female
Switching Indication
GFC 1716A
