Digital Input
Item Dl-6261 DI-6271 DI-6271 H Dl-6249
Input voltage 10 - 30 Vdc i
Min. ON voltage 9.6 V 8,5 V _______
Max. OFF voltage 4.8 V 4.0 V ^
Input current 10 mA (24 Vdc)
Input points 16 pts (8 pts common) 32 pts (16 pts common) 64 (dynamic scan)
ON delay Less than 10 ms Less than 1.0 ms Less than 1.7 ms
OFF deUy Less than IS ms Less than 1.5 ms Less than 1.7 ms
Consumed current Less than 50 mA (5 V) Less chan 80 mA (5 V) Less than 100mA (5 V)
Weight 470 g 550 g 500 g
Item INP-6262 INP-6272 INP-6266 INP-6276
Input voltage 85 - 132 Vac 170 - 250 Vac 85 - 132 Vac 170- 250 Vac
Min. ON voltage 75 V 150 V 75 V ISO V
Max. OFF voltage 25 V 50 V 25 V SO V
Input current 14 mA (100 Vac) 14 mA (200 Vac) 10 mA (100 Vac) 10 mA (200 Vac)
Input points
ON delay
OFF delay
Consumed current
Weight
16 points
Less than IS ms
Less than 15 ms
Less than 70 mA (5 V)
SlOg
32 points
Less than 25 ms
Less than 20 ms
Leas than 100 mA (5 V)
550 g
Digital Output
Item DO-6263 DO-6273 RO-6265 RO-6275
Output voltage 10-30 Vdc 250 Vac/30 Vdc (max)
Load current 2 A/pnt. 5 A/common 0.5 A/pni, 5 A/common 2 A/pnt, 8 A/common 2 A/pnt, 16 A (total)
Output point 16 pts (8 pts common) 32 pts (16 pts common) 16 pts (8 pts common) 16 pts (independent)
ON delay Les.s than 1 ms Less than 10 ms
OFF delay Less Chan 1 ms Less than 15 ms
Leakage current 100 fiA 10 M Non
Consumed current Less than 140 mA (5 V) Less than 200 mA (5 V) Less than 80 mA (5 V)
WeiAt 550 g 700 g 650 g
Item ACO-6264 ACO-6274 ACO-6269
Output voltage 85 - 132 Vac no - 250 Vac 24 - 250 Vac (+10/-15%)
Load current 2 A/pnl, 5 A/common 0.5 A/pnt, 3.2 A/common, 5 A (total)
Output points
ON delay
OFF delay
Leakage current
Consumed current
Weight
16 pts (S pts common)
Less than 2 ms
Less than 12 ms
1 mA (100 V/30 Hz)
Less than 230 mA (5 V)
2 mA (200 V/50 Hz)
Less than 400 mA (5 V)
550 g
32 pts (16 pts common)
Less than 1 ms
Less than 1/2 cycle
1 mA (100 V/50 Hz)
Less than 800 mA
800 g
