Chapter 2 Installation
8 M15-155 Installation Guide
Power-on Check
When you plug in the M15-155, wait until first the CPU LED lights and then the
OPR lights steadily before commencing work. If there are several M15-155
modules, one module will be elected as the Master Agent, and the NMA LED on
that module will also light ON. For a detailed explanation of the Master Agent
please refer to the Avaya M770 ATM Switch User’s Guide.
Connecting the Console Terminal
Initial software configuration of the M15-155 is done using a console terminal
connected to the Console connector on the front panel of the module. See the
Appendix for connector pin assignments.
To connect the M15-155 to a console terminal:
1. Turn on the VT100 terminal (or PC terminal emulator in VT100 or VT52 mode)
and set its communication parameters to:
Baud rate:
9600 bps
Start bit: 1
Data bits: 8
Stop bit: 1
Parity: None
Refer to your terminal’s user manual for instructions on how to set these
parameters.
2. Insert the RJ-45 connector of the cable into the Console port on the M15-155
front panel (see Table 3 for connector pinout).
3. Insert the other end of the cable into the terminal’s RS-232 port.
4. Press
to verify that the cabling process was successful. The system
prompt appears (M770sXX:/>).
5. The CLI commands and the explanation of how to configure the switch are
described in the Avaya M770 ATM Switch User’s Guide.
